Cooking modes

Convection.
Economy convection. Top + bottom heat. Top heat. Bottom heat. Convection + bottom heat. Convection broiling. Broiling. Economy broiling. Baking stone operation. Roaster operation. Dough proofing. Defrosting.

​

Operation

Rotary knob and TFT touch display operation.

Clear text display in 44 languages.

Option to save 50 individual recipes (incl. core temperature probe)

Personalization of automatic programs.

Information key with use indicators.

Side-opening door opens up to 110° angle.

​

Features

Three-point core temperature prove with automatic shut-off and estimation of cooking time.

Automatic programs.

Baking stone outlet.

Actual temperature display.

Fast heating setting.

60 W halogen light on the top.

Enamelled side shelf supports with 4 tray levels, pyrolysis-safe.

Home network integration for digital services (Home Connect) either via cable connection LAN (recommended) or wireless via WiFi.

The use of the Home Connect functionality depends on the Home Connect services, which are not available in every country. For further information please check: home-connect.com.

​

Safety

Thermally insulated door with quintuple glazing.

Child lock.

Safety shut-off.

Cooled housing with temperature protection.

​

Cleaning

Pyrolytic self-cleaning.

Gaggenau Clean-Enamel.

Heated air cleaning catalyst.

​

Planning notes

Door hinge not reversible.

The door panel front of the appliance extends 13/16" from the cabinet front.

The outer edge of the door handle extends 2 13/16" from the cabinet front.

Necessary lateral gap between appliance door and cabinet front of min. 3/16".

Consider the overhang, incl. the door handle, when planning to open drawers next to the appliance.

When planning a corner solution, pay attention to the 110° door opening angle.

For installation underneath cooktops:
Distance between the underside of the cooktop and the top edge of the oven cavity: min. 9/16". The planning notes for the cooktops (particularly regarding ventilation, gas/ electric connection) must be taken into account.

To achieve the 21 ⅝" (550 mm)
installation depth, the connection cable needs to follow the slanted edge on the corner of the housing.

Plan a power outlet outside of the
cut-out niche.

The LAN port can be found at the back on the upper right side.

​

Rating

Total rating 4.0 KW.

Total Amps: 17 A.

208 - 240 V / 60 Hz.

Connecting cable 63 without plug (hardwire required).

Plan for an ethernet / LAN cable or connect via WiFi.

Power consumption standby/display off 0.5 W.

Power consumption standby/network 1.4 W.

Time auto-standby/network 20 min.

Please check the user manual for how to switch off the WiFi module.
